P16AP Ultra Hydraulic Hose Crimping Machine
Feature description Hydraulic Hose Crimping Machine：
● Super Compact
● No electricity required
● Enerpac Pneumatic Pump
● Complete Die Set
Specification：
| Main Specification |
SAMWAY P16AP Ultra |
| Max Hydraulic Hose |
1" 3 wire |
| Crimping Range mm |
4-45 |
| Die Type |
P16 |
| Master Die Length mm |
64 |
| Max Opening mm |
+20 |
| Hand Pump |
Enerpac two stage Pneumatic pump 700 bar |
| Crimping Force KN |
1000 |
| Control |
Micro Dail |
| L*W*H mm |
280*300*250 |
| Weight KG |
25 |
Standard Die Sets Included：
| Die No. |
10 |
12 |
14 |
16 |
19 |
23 |
27 |
31 |
| Length |
55 |
55 |
55 |
55 |
55 |
55 |
65 |
65 |
Order No:
Hand Pump Model P16HP :00001810
Pneumatic Pump Model P16AP :00001811
