Working pressure (static): 26 bar (370 PSI)
Radiator material: Aluminium
Application: Agriculture
| Order Number |
Description |
Motor Power |
Current |
Noise Level |
Weight |
| ASA0023UD01 |
LL 02 12V DC |
0.1 HP |
5.4 A |
73 db(A) |
5.94 lbs |
| ASA0023UD02 |
LL 02 24V DC |
0.1 HP |
2.7 A |
73 db(A) |
5.94 lbs |
Technical Data
- ASA0023UD01
| Motor Size: |
- |
|
| Current: |
5.4 |
A |
| Frequency: |
- |
|
| Noise Level: |
73 |
db(A) |
| Weight: |
5.94 |
lbs |
| Oil Pressure: |
- |
|
| Oil Flow: |
- |
|
| Rotation: |
3280 |
RPM |
| Air Flow: |
247.1 |
SCFM |
| Protection Level: |
IP 68 |
|
- ASA0023UD02
| Motor Size: |
- |
|
| Current: |
2.7 |
A |
| Frequency: |
- |
|
| Noise Level: |
73 |
db(A) |
| Weight: |
5.94 |
lbs |
| Oil Pressure: |
- |
|
| Oil Flow: |
- |
|
| Rotation: |
3280 |
RPM |
| Air Flow: |
247.1 |
SCFM |
| Protection Level: |
IP68 |
|
Electronic
Coolers that are labeled with the shown symbol are available with various electronic controls.
Temperature Control
The temperature control consists of a temperature sensor and a control unit that controls the fan speed according the actual oil temperature. This lowers the noise level of the cooler and increases the durability of the fan motor, because it is not running on maximum speed all the time.
Thermostat
Also available are various thermostats for all coolers types.
