Trademark: HYDROMAX
Model: HGP-0.5A
Displacement : 0.35~1.13 cc/rev
Max. Pressure : 250 kgf/cm2 ( 3500psi )
Made in: Taiwan
Mã đặt hàng:
|
Model Name
|
HGP-05A
|
|
Mounting
|
F Flange Type
|
|
L Foot Type
|
|
Delivery Capacity
|
03,05,08,1.1
|
|
Rotation Direction
|
R Clockwise
|
|
L Counter-Clockwise
|
|
Shaft Type
|
X Straight Shaft
|
Value table
|
Model
|
Accurate
|
Pressure
|
(kgf/cm2)
|
Speed
|
(r.p.m)
|
|
|
|
Weight(kg)
|
|
Displacement
|
Port Size
|
(PT)
|
|
Capacity
|
|
|
|
(cc/rev)
|
normal
|
Max
|
Rate
|
Max
|
Min
|
Inlet
|
Outlet
|
|
HGP-05A-03
|
0.35 |
210 |
250 |
1800 |
3500 |
800 |
1/8" |
1/8" |
0.40 |
|
HGP-05A-05
|
0.56 |
210 |
250 |
1800 |
3500 |
800 |
1/8" |
1/8" |
0.42 |
|
HGP-05A-08
|
0.85 |
210 |
250 |
1800 |
3500 |
800 |
1/4" |
1/4" |
0.43 |
|
HGP-05A-11
|
1.13 |
210 |
250 |
1800 |
3500 |
800 |
1/4" |
1/4" |
0.44 |
Value table
|
Model
|
Accurate
|
Pressure
|
(kgf/cm2)
|
Speed
|
(r.p.m)
|
|
|
|
Weight(kg)
|
|
Displacement
|
Port Size
|
(PT)
|
|
Capacity
|
|
|
|
(cc/rev)
|
normal
|
Max
|
Rate
|
Max
|
Min
|
Inlet
|
Outlet
|
|
HGP-05A-03
|
0.35 |
210 |
250 |
1800 |
3500 |
800 |
1/8" |
1/8" |
0.40 |
|
HGP-05A-05
|
0.56 |
210 |
250 |
1800 |
3500 |
800 |
1/8" |
1/8" |
0.42 |
|
HGP-05A-08
|
0.85 |
210 |
250 |
1800 |
3500 |
800 |
1/4" |
1/4" |
0.43 |
|
HGP-05A-11
|
1.13 |
210 |
250 |
1800 |
3500 |
800 |
1/4" |
1/4" |
0.44 |
