Key Features
The range of our tandem gear pumps and hydraulic rotary motor are available in 4 basic sizes for flows up to 108 lpm and pressure up to 250 bar (3550 psi), and the single and the multiple units are offered having a variety of shaft, flange and connection options, which fit SAE, European and German standards.
And we use the high tensile extrude aluminum alloy body and die casting covers machined to ensure high volumetric, mechanical efficiency and low noise level. Moreover, the Viton O-ring and back-up ring of our products guarantee high temperature proof and the Internal bearing design ensures the high pressure capacity.
As to the rotating direction of our motor, clockwise, counter-clockwise and reverse rotations are all available. The synchronous flow divider which is equipped with our product can be assembled as multiple stages as requirements , the synchronous accuracy can achieve 95% compare than 70% of dividing valve. Besides, for comprehensive applications, our gear pump can be optionally mounted with cartridge relief or lifting valves.
1. Product Information
Product Category: Cartridge Solenoid Check Valve
Item: Lift Valve 250/350kg - PR1+V2064
Brand: HYDROMAX
Model: PR1+V2064
Country of Origin: Taiwan
2. Product specification:
| Max Flow |
20 |
LPM |
| Max Pressure |
210 |
bar |
| Flange Type |
JIS 4 bolt |
|
3. Accessory:
| |
|
Order Code |
| Flange Type |
JIS 4-bolt |
Omit |
